MONO-90W And PLOY-90W

Short Description:

Quantity per Pallet:40

MONO-90W Pallet Dimension (mm):L697×Wl,110 × H988

MONO-90W Net Weight per Pallet:241.6 kg

MONO-90W Gross Weight per Pallet:291.6 kg

PLOY-90W Pallet Dimension (mm):L697 × Wl,110 × Hl,074

PLOY-90W Net Weight per Pallet:266.8 kg

PLOY-90W Gross Weight per Pallet:316.8 kg


Product Detail

Product Tags

Product Description

Carefully Designed For Compact Solar Systems

Meets the requirements of Off-Grid Systems for various segments

3

Customized & OEM Service

Customized Designed ( any size, voltage, cable requirement) .

304

ALife Solar have a qualified team experienced at R&D, production, quality control and management with competitive prices for all its products and services. All its products have certificates of TUV, IEC, UL, CE, CEC and so on.

Details Show

603

Solar Cell:
>> High module conversion efficiency (up to 15.60%)
>> Positive power output tolerance ensures high reliability
>> Excellent performance under low light environments (mornings,evenings and cloudy days)
>> PID Free Treatment

Glass :
>> Tempered Glass
>> Self-cleaning function
>> Anti-reflective,hydrophobic coating improves light absorption and reduces surface dust
>> Entire module certified to withstand high wind loads and snow loads
>>10 year material and workmanship warranty.

604
605

Frame:
>> Anodized Aluminum Alloy
>> Black Frame is optional as well
>> Seal-lip designlue injuection
>> Serrated-clip design tensile strength
>> Boost Bearing capability and long service life

Junction Box:
>> IP65 or IP67 Protection Level
>> 4mm2(IEC)/12AWG(UL) Cable
>> MC4 or MC4 Comparable Connectors
>> Heat dissipation Protection function
>> Client special customed requirement is option

606

Our Projects

9005

1.5MW Village Poverty Alleviation Power Stations in Thailand

9006

6.6KW PV System Residential Rooftop in England

4007

5KW Residential Power Station in Australia

Certifications

5005

MONO-90W Product Details

STC : 1000W/m2, 25°C, 1.5AM   NOCT : 800W/m2, 45±2°C,1m/s wind speed

ELECTRICAL PARAMETERS STC

NOCT

Power Output Pmax W 90

65.52

Power Output Tolerances △Pmax % -5%~+10%

-5%~+10%

Voltage at Pmax Vmpp V 18.08

16.89

Current at Pmax Impp A 4.98

3.88

Open-Circuit Voltage Voc V 21.28

19.88

Short Circuit Current Isc A 5.78

4.66

Max System

VSYS

V 60

60

Temperature Characteristics
Nominal Operating Cell Temperature NOCT

°C

45 ±2 °C

Temperature Coefficient of Pmax

γ

%/°c

-0.45

Temperature Coefficient of Voc

βVoc

%/°c

-0.33

Temperature Coefficient of Isc

αIsc

%/°c

+0.039

Temperature Coefficient of Vmpp

βVmpp

%/°c

-0.33

Mechanical Characteristics
Cell Type

Mono Crystaline Silicon

Module Dimension (mm)

L665 ×W826 × H25

Module Weight

6.04 kg

Front Layer

3.2 mm Tempered Glass

Encapsulant

Ethylene-Vinyl Acetate

Frame

Anodized Alluminum Aloy, Silver Color, 25 mm

Junction Box

IP 64

Cable

16 AWG

Back Layer

PV Backsheet, White

Warranty
Certification

ISO 9001, ISO 14000, ISO 45001 TUV, CE, RoHS, REACH

Product

5 years

90
91

PLOY-90W Product Details

STC : 1000W/m2,  25°C, 1.5AM  NOCT : 800W/m2,45±2°C, 1 m/s wind speed

ELECTRICAL PARAMETERS STC

NOCT

Power Output Pmax W 90

65.52

Power Output Tolerances △Pmax % -5%~+10%

-5%~+10%

Voltage at Pmax Vmpp V 19.44

18.16

Current at Pmax Impp A 4.63

3.61

Open-Circuit Voltage Voc V 22.5

21.02

Short Circuit Current Isc A 5.39

4.35

Max System

VSYS

V 60

60

Packaging
Quantity per Pallet 40
Pallet Dimension (mm) L697 x W1,110 x H1,074
Net Weight per Pallet 266.8 kg
Gross Weight per Pallet 316.8 kg
Qantity in 20" CNTR 1,280
Temperature Charateristics
Nominal Operating Cell Temperature

NOCT

°C

45 ±2 °C

Temperature Coefficient of Pmax

γ

%/°c

-0.45

Temperature Coefficient of Voc

βVoc

%/°c

-0.33

Temperature Coefficient of Isc

αIsc

%/°c

+0.039

Temperature Coefficient of Vmpp

βVmpp

%/°c

-0.33

Mechanical Charateristics
Cell Type

Poly Crystaline Silicon

Module Dimension (mm)

L665 × W912 × H25

Module Weight

6.67 kg

Front Layer

3.2 mm Tempered Glass

Encapsulant

Ethylene-Vinyl Acetate

Frame

Anodized Alluminum Aloy, Silver Color, 25 mm

Junction Box

IP 64

Cable

16 AWG

Back Layer

PV Backsheet, White

Warranty
Certification

ISO 9001, ISO 14000, ISO 45001 TUV,CE, RoHS, REACH

Product

5 years

902
901

FAQ

1. What things to avoid when buying a solar PV system? The following are the things are to avoid when buying a solar PV system that can undermine the system's functionality:

· Incorrect design principles.

· Inferior product line used.

· Incorrect installation practices.

· Nonconformance on safety issues.

2. What is the guide for warranty claim in China or International? The warranty could be claimed by the customer support of a particular brand in the client's country.

In case, there is no customer support available at your country, the client can ship it back to us and the warranty would be claimed in China. Please note that the client has to bear the expense of sending and receiving back the product in this case.

3. Payment procedure (TT, LC or other available methods)

Negotiable, depending upon customer's order.

4. Logistics info (FOB China)

Main port as Shanghai/Ningbo/Xiamen/Shenzhen.

5. How can I check if the components offered to me are of the best quality?

Our products have certifications such as TUV, CAS, CQC, JET and CE of quality control, related certifications can be provided upon request.

6. What is the point of origin of ALife's products? Are you a dealer of a certain product?

ALife assures all marketable products are from original brands factory and support back to back warranty. ALife is an authorized distributor also approve the certification to customers.

7. Can we get a Sample?

Negotiable, depending upon customer's order.
