MONO-120W And PLOY-120W

Short Description:

Quantity per Pallet:35

MONO-120W Pallet Dimension (mm):Ll,049 × Wl,150 × H827

MONO-120W Net Weight per Pallet:312.55 kg

MONO-120W Gross Weight per Pallet:362.55 kg

PLOY-120W Pallet Dimension (mm):Ll,150 × Wl,156 × H827

PLOY-120W Net Weight per Pallet:345.45 kg

PLOY-120W Gross Weight per Pallet:395.45 kg


Product Detail

Product Tags

Product Description

Carefully Designed For Compact Solar Systems

Meets the requirements of Off-Grid Systems for various segments

3

Our Advantages

Status
ALife Solar is a comprehensive and high-tech photovoltaic enterprise being engaged in the R&D, production and sales of solar products.more than 10-year,focus on new solar product R&D.

Certification&Technology
Certificated by TUV\CE\ROHS\EMC\LVD, ALifeSolar grasps core solar panel production technology,promises all products passed IV test(power ins- pection) and EL test (cells inspection).

Stock
Short lead-time: Faster producing time comparing with other suppliers within 12 working days,and always prepared for in stock.

Product&Customization
Offering diversified solar product: Glass solar panel,Flexible solar panel,Solar charger,Foldable solar panel,Foldable solar kit,Customized solar panel from 0.5-600w.

Quality
Cooperating with stable brand mate- rial supplier and national shipping company,ALifeSolar produces more than 700MW per year,and steadi- ly increase 20% yearly.

Service
Offering sincere on call service and professional product suggestion. All after-sale problem would be offer with a satisfactory solution in one week.

Details Show

603

Solar Cell:
>> High module conversion efficiency (up to 15.60%)
>> Positive power output tolerance ensures high reliability
>> Excellent performance under low light environments (mornings,evenings and cloudy days)
>> PID Free Treatment

Glass :
>> Tempered Glass
>> Self-cleaning function
>> Anti-reflective,hydrophobic coating improves light absorption and reduces surface dust
>> Entire module certified to withstand high wind loads and snow loads
>>10 year material and workmanship warranty.

604
605

Frame:
>> Anodized Aluminum Alloy
>> Black Frame is optional as well
>> Seal-lip designlue injuection
>> Serrated-clip design tensile strength
>> Boost Bearing capability and long service life

Junction Box:
>> IP65 or IP67 Protection Level
>> 4mm2(IEC)/12AWG(UL) Cable
>> MC4 or MC4 Comparable Connectors
>> Heat dissipation Protection function
>> Client special customed requirement is option

606

Who We Are

ALife Solar is a comprehensive and high-tech photovoltaic enterprise being engaged in the R&D, production and sales of solar products. As one of the leading pioneers of solar panel, solar inverter, solar controller , solar pumping systems,solar street light, research &development, production &sales in china, ALife Solar distributes its solar products and sells its solutions and services to a diversified international utility, commercial and residential customer base in China, the United States, Japan, Southeast Asia,Germany, Chile, South Africa, India, Mexico, Brazil, the United Arab Emirates, Italy, Spain, France, Belgium, and other countries and regions. Our company regards 'Limited Service Unlimited Heart' as our tenet and serve customers wholeheartedly. We specialized in sales of high quality of solar system and P V modules, including the customized service, We are in good position of the global solar trade business, hope to establish business with you then we can realize a win-win result.

Workshop

momo-60w (5)
momo-60w (4)
momo-60w (3)
momo-60w (2)
momo-60w (1)
momo-60w (8)
momo-60w (7)
momo-60w (6)

MONO-120W Product Details

STC : 1000W/m2, 25°C, 1.5AM  NOCT : 800W/m2,45±2°C, 1m/s wind speed

ELECTRICAL PARAMETERS STC

NOCT

Power Output Pmax W 120

87.36

Power Output Tolerances △Pmax % -5%~+10%

-5%~+10%

Voltage at Pmax Vmpp V 18.08

16.89

Current at Pmax Impp A 6.64

5.17

Open-Circuit Voltage Voc V 21.28

19.88

Short Circuit Current Isc A 7.24

5.83

Max System

VSYS

V 60

60

Packaging
Quantity per Pallet 35
Pallet Dimension (mm) L1,049 x W1,150 x H827
Net Weight per Pallet 312.55 kg
Gross Weight per Pallet 362.55 kg
Qantity in 20" CNTR 700
Temperature Characteristics
Nominal Operating Cell Temperature

NOCT

°C

45 ±2 °C

Temperature Coefficient of Pmax

γ

%/°c

-0.45

Temperature Coefficient of Voc

βVoc

%/°c

-0.33

Temperature Coefficient of Isc

αIsc

%/°c

+0.039

Temperature Coefficient of Vmpp

βVmpp

%/°c

-0.33

Mechanical Characteristics
Cell Type

Mono Crystaline Silicon

Module Dimension (mm)

L665 × Wl,017 × H30

Module Weight

8.93 kg

Front Layer

3.2 mm Tempered Glass

Encapsulant

Ethylene-Vinyl Acetate

Frame

Anodized Alluminum Aloy, Silver Color, 30 mm

Junction Box

IP 64

Cable

14 AWG

Back Layer

PV Backsheet, White

Warranty
Certification

ISO 9001, ISO 14000, ISO 45001 TUV,CE, RoHS, REACH

Product

5 years

121
122

PLOY-120W Product Details

STC : 1000W/m2,  25°C, 1.5AM  NOCT : 800W/m2,45±2°C, 1 m/s wind speed

ELECTRICAL PARAMETERS STC

NOCT

Power Output Pmax W 120

87.36

Power Output Tolerances △Pmax % -5%~+10%

-5%~+10%

Voltage at Pmax Vmpp V 19.44

18.16

Current at Pmax Impp A 6.17

4.81

Open-Circuit Voltage Voc V 22.5

21.02

Short Circuit Current Isc A 6.74

5.43

Max System

VSYS

V 60

60

Packaging
Quantity per Pallet 35
Pallet Dimension (mm) L1,150 x W1,156 x H827
Net Weight per Pallet 345.45 kg
Gross Weight per Pallet 395.45 kg
Qantity in 20" CNTR 700
Temperature Charateristics
Nominal Operating Cell Temperature

NOCT

°C

45 ±2 °C

Temperature Coefficient of Pmax

γ

%/°c

-0.45

Temperature Coefficient of Voc

βVoc

%/°c

-0.33

Temperature Coefficient of Isc

αIsc

%/°c

+0.039

Temperature Coefficient of Vmpp

βVmpp

%/°c

-0.33

Mechanical Charateristics
Cell Type

Poly Crystaline Silicon

Module Dimension (mm)

L665 × Wl,124 × H30

Module Weight

9.87 kg

Front Layer

3.2 mm Tempered Glass

Encapsulant

Ethylene-Vinyl Acetate

Frame

Anodized Alluminum Aloy, Silver Color, 30 mm

Junction Box

IP 64

Cable

14 AWG

Back Layer

PV Backsheet, White

Warranty
Certification

ISO 9001, ISO 14000, ISO 45001 TUV,CE, RoHS, REACH

Product

5 years

1202
1201

Product Application

6

Our Projects

9005
9006
4007

1.5MW Village Poverty Alleviation Power Stations in Thailand

6.6KW PV System Residential Rooftop in England
